Supermicro X9DRW-iF User Manual

Chapter 2: Installation
2-15
Populating LRDIMM (ECC) Memory Modules
Intel E5-2600(v2) Series Processor LRDIMM Memory Support
Ranks
Per
DIMM
&
Data
Width
Memory
Capacity
Per DIMM
(See the Note
Below)
Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per
Channel (DPC)
2 Slots Per Channel 3 Slots Per Channel
1DPC 2DPC 1DPC 2DPC 3DPC
1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V
QRx4
(DDP)
16GB 32GB 1066,
1333,
1600
1066,
1333,
1600,
1866
1066,
1333,
1600
1066,
1333,
1600
1066,
1333,
1600
1066,
1333,
1600,
1866
1066,
1333,
1600
1066,
1333,
1600
1066 1066
8Rx4
(QDP)
32GB 64GB 1066 1066 1066 1066 1066 1066 1066 1066 1066 1066
Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory
List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.
Intel E5-2600 Series Processor LRDIMM Memory Support
Ranks
Per
DIMM
&
Data
Width
Memory
Capacity
Per DIMM
(See the Note
Below)
Speed (MT/s) and Voltage Validated by Slot per Channel (SPC) and DIMM Per
Channel (DPC)
2 Slots Per Channel 3 Slots Per Channel
1DPC 2DPC 1DPC 2DPC 3DPC
1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V 1.35V 1.5V
QRx4
(DDP)
16GB 32GB 1066 1066,
1333
1066 1066,
1333
1066 1066,
1333
1066 1066,
1333
1066 1066
QRx8
(QDP)
8GB 16GB 1066 1066,
1333
1066 1066,
1333
1066 1066 1066 1066 1066 1066
Note: For detailed information on memory support and updates, please refer to the SMC Recommended Memory
List posted on our website at http://www.supermicro.com/support/resources/mem.cfm.
Other Important Notes and Restrictions
•For the memory modules to work properly, please install DIMM modules of the same
type, same speed and same operating frequency on the motherboard. Mixing of
RDIMMs, UDIMMs or LRDIMMs is not allowed. Do not install both ECC and Non-ECC
memory modules on the same motherboard.
•Using DDR3 DIMMs with different operating frequencies is not allowed. All channels
in a system will run at the lowest common frequency.
•Due to memory allocation to system devices, the amount of memory that remains
available for operational use will be reduced when 4 GB of RAM is used. The
reduction in memory availability is disproportional. See the table on the next
page for details.

Supermicro X9DRW-iF Specifications

General

PS/2 ports quantity	0
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Memory channels	Dual-channel
Maximum RDIMM memory	512 GB
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	800, 1066, 1333, 1600 MHz
Maximum UDIMM memory	128 GB
Number of DIMM slots	16
Supported RDIMM module capacity	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
Supported UDIMM module capacity	1GB, 2GB, 4GB, 8GB
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I350
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Matrox G200
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Processor thermal power (max)	135 W
Processor number of cores supported	6, 8
Component for	Server
Motherboard chipset	Intel® C602
Sustainability certificates	RoHS

Weight and Dimensions

Depth	330 mm
Width	305 mm
