Supero C7Z270-PG User Manual

Chapter 1: Introduction
1-11
Connector Description
AUDIO FP Front Panel Audio Header
B1 Onboard Battery
COM1 COM1 Port Header
FANS 1-5 System/CPU Fan Headers (Fan 1, Fan 4: CPU Fans;
Fan 2, Fan 3, Fan 5: System Fans)
HD Audio High Denition Audio Ports
HDMI/DP High Denition Multimedia Interface/Display Port
I-SATA0~5
(Intel
®
Z270) Serial ATA (SATA 3.0) Ports 0~5 (6Gb/sec)
JD1 Speaker/buzzer (Pins 1~4: External Speaker, Pins 3~4:
Buzzer)
JF1 Front Control Panel Header
JL1 Chassis Intrusion Header
JLED1 Power LED Indicator Header
JPW1 24-pin ATX Main Power Connector (Required)
JPW2 +12V 8-pin CPU power Connector (Required)
JSD1 SATA DOM (Disk On Module) Power Connector
JSPDIF_OUT Sony/Philips Digital Interface Format (S/PDIF) Out
Header
JSTBY1 Standby Power Header
JTBT Thunderbolt Connector
JTPM1 Trusted Platform Module (TPM) Header
KB/MOUSE PS2 Keyboard/Mouse Connectors
LAN1/LAN2 RJ45 Gigabit LAN Ports
MH 10-12 Mounting holes for PCI-E M.2 Connector 1
MH 13-15 Mounting holes for PCI-E M.2 Connector 2
PCI-E M.2 CONNECTOR 1, 2 PCIE M.2 Connectors 1 and 2, small form factor devices
and other portable devices for High speed NVMe SSDs
Slot 1/7 CPU PCI-E 3.0 x16 Slots
Slot 3/5 CPU PCI-E 3.0 x8 (IN x16) Slots
Slot 4 PCH PCI-E 3.0 x4
SP1 Internal Speakers
U.2 CONNECTOR 1, 2 U.2 Connector 1 and 2, for 2.5” SSD Drives
