5-14
SUPERSERVER 6027TR-HTRF+/H70RF+/H71RF+ User's Manual
Notes:
1. For the latest CPU/Memory updates, please refer to our website at http://
www.supermicro.com/products/motherboard/ for details.
2. Use only the correct type of onboard CMOS battery as specifi ed by the
manufacturer. Do not install the onboard battery upside down to avoid
possible explosion.
3. Jumpers not indicated are for test purposes only.
4. All graphics shown in this manual were based upon the latest PCB Revision
available at the time of publishing of the manual. The motherboard you've
received may or may not look exactly the same as the graphics shown in this
manual.
X9DRT-HF+ Quick Reference
Jumper Description Default Setting
JBT1 Clear CMOS See Page 5-19
JPB1 BMC Enable/Disable Pins 1-2 (Enabled)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 Ethernet GLAN1/GLAN2 Enable/Disable Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
LED Description State Status
LE1 Onboard PWR LED On Onboard PWR On
LE2 UID LED
Blue: On (Windows OS
Blinking (Linux)
Unit Identifi ed
LE3 HDD LED Green: On HDD/SATA Active
LEM1 BMC Heartbeat LED Green: Blinking BMC Normal
