Chapter 5: Advanced Motherboard Setup
5-15
Connector Description
JBAT1 Onboard battery (see warning in chapter 4)
I-SATA 0/1 Intel PCH SATA Connectors 0/1
JF2 SMC Proprietary Slot for Power, FP Control & I-SATA Connections
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JPTM1 TPM (Trusted Platform Module)/Port 80
LAN1/2 G-bit Ethernet Ports 1/2
(IPMI) LAN IPMI_Dedicated LAN
Slot1 (CPU1) PCI-E 3.0 x8 slot for SMC-proprietary Daughter (Add-on) card
Slot2 (CPU1) PCI-E 3.0 x8 slot for SMC-proprietary Micro low-profi le (LP) card
UIDSW1 UID (Unit Identifi er) Switch
USB 0/1 Back Panel USB 0/1 ports
USB 2/3 Front Accessable USB Connections 2/3
USB 4 Type-A USB Connection (USB4) for front access
VGA Backpanel VGA Port
