NMI Button
The non-maskable interrupt button
header is located on pins 19 and 20
of JF1. Refer to the table on the right
for pin defi nitions.
NMI Button
Pin Defi nitions
(JF1)
Pin# Defi nition
19 Control
20 Ground
HDD LED
The HDD LED connection is located
on pins 13 and 14 of JF1. Attach the
hard drive LED cable here to display
disk activity (for any hard drives on the
system, including SAS, Serial ATA and
IDE). See the table on the right for pin
defi nitions
HDD LED
Pin Defi nitions
(JF1)
Pin# Defi nition
13 Vcc
14 HD Active
Power On LED
The Power On LED connector is
located on pins 15 and 16 of JF1. This
connection is used to provide LED
indication of power being supplied to
the system. See the table on the right
for pin defi nitions.
Power LED
Pin Defi nitions
(JF1)
Pin# Defi nition
15 5V Stby
16 Control
Ethernet Ports
Two Gigabit Ethernet ports (LAN1,
LAN2) are located on the I/O backplane
on the motherboard. In addition, an
IPMI_Dedicated LAN is located above
USB 0/1 ports on the backplane to
provide KVM support for IPMI 2.0. All
these ports accept RJ45 type cables.
Please refer to the LED Indicator
Section for LAN LED information.
LAN Ports
Pin Defi nition (LAN 1/2)
Pin# Defi nition Pin# Defi nition
1 P2V5SB 10 SGND
2 TD0+ 11 Act LED
3 TD0- 12 P3V3SB
4 TD1+ 13 Link 100 LED
(Yellow, +3V3SB)
5 TD1- 14 Link 1000 LED
(Yellow, +3V3SB)
6 TD2+ 15 Ground
7 TD2- 16 Ground
8 TD3+ 17 Ground
9 TD3- 18 Ground
(NC = No Connection)
