Supero X10SRL-F User Manual

1-6
X10SRL-F User’s Manual
Motherboard Features
CPU Single Intel
®
E5-2600/1600 Series processor in an
LGA2011 R3 socket.
Memory Eight (8) ECC/Non-ECC DDR4 RDIMM/LRDIMM/UDIMM
at 1333/1600/1866/2133 MHz memory (1 DPC) up to
256GB RDIMM, 512GB LRDIMM, or 64GB UDIMM.
Dual-channel memory
DIMM sizes
RDIMM 1GB, 2 GB, 4GB, 8GB, 16GB, and
32GB
Chipset Intel
®
C612 Express
Expansion Slots One (1) PCI Express 2.0: 1 (x4 in x8)
Six (6) PCI Express 3.0: 2 (x8 in x16), 2 (x8), 1 (x8 or x4),
1 (x0 or x4)
Two (2) RJ-45 rear I/O panel connectors with Link and
Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s)
Ten (10) SATA3 ports
•AHCI controller supports six (6)
SATA3 drives compatible with
RAID 0, 1, 5, 10.
•sSATA controller supports four
(4) SATA3 drives compatible
with RAID 0, 1, 5, 10.
•RAID array and volume(s) can-
not span across the two (AHCI
and sSATA) controllers.
SATA DOM Two (2) SATA DOM Ports (SATA 4/5)
USB Devices
Eight (8) USB 2.0 ports ( 2 rear, 6 via headers)
Four (4) USB 3.0 headers for USB 3.0 support (2 rear, 1
Type-A, 1 via header)
Serial (COM) Ports
Two (2) COM Ports (1 header, 1 rear)
Graphics Controller
AST 2400 Graphics Controller
Network One i210 Dual-Channel Gigabit (100/1000 MB/s)
Ethernet Contoller for LAN 1/LAN 2 ports
