Video Connector
A Video (VGA) connector is located
next to the COM Port on the I/O
backpanel. This connector is used
to provide video and CRT display.
Refer to the board layout below for
the location.
VGA/CRT Pin
Denitions
Pin# Denition Pin# Denition
1 Red 10 Ground
2 Green 11 MS0
3 Blue 12 MS1: SDA (DDC Data)
4 MS2 13 HSYNC
5 Ground 14 VSYSNC
6 Ground 15 MS3: SCL (DDC CLK)
7 Ground 16 Case
8 Ground 17 Case
9 NC
NC= No Connection
A
A. TPM/Port 80
B. VGA Port
TPM Header/Port 80 Header
A Trusted Platform Module/Port 80
header is located at JTPM1 to provide
TPM support and Port 80 connection.
Use this header to enhance system
performance and data security. See
the table on the right for pin deni-
tions.
TPM/Port 80 Header
Pin Denitions
Pin # Denition Pin # Denition
1 LCLK 2 GND
3 LFRAME# 4 <(KEY)>
5 LRESET# 6 +5V (X)
7 LAD 3 8 LAD 2
9 +3.3V 10 LAD1
11 LAD0 12 GND
13 SMB_CLK 14 SMB_DAT
15 +3V_STB 16 SERIRQ
17 GND 18 CLKRUN#
19 LPCPD# 20 LDRQ# (X)
