Appendix D: Dual Boot Block
D-7
D-2
IPMI Co
mmand Sets
T
o perform perform the Dual Boot Block through the IPMI Command Sets, follow
the instructions below:
1.
After the IPMI GUI browser log-in, click on the
Remote Control
tab, then
Console Redirection
, then the
Launch Console
button to open Java iKVM
Viewer
.
2.
Open a DOS command prompt for SMCIIPMIT
ool execution. T
ype
ipmi
power down
to power off the defective system.
128
130
