Chapter 2: Installation
2-15
Populating RDIMM Memory Modules
2
Slots
per
Channel
RDIMM
Population
Congurations
Conguration
Number
POR Speed
DIMM1
DIMM0
1
DDR4-2133,
1866, 1600
Empty
Single-rank
2
DDR4-2133,
1866, 1600
Empty
Dual-rank
3
DDR4-1866,
1600
Single-rank
Single-rank
4
DDR4-1866,
1600
Single-rank
Dual-rank
5
DDR4-1866,
1600
Dual-rank
Dual-rank
Populating LRDIMM Memory Modules
2
Slots
per
Channel
LRDIMM
Population
Congurations
Conguration
Number
POR Speed
DIMM1
DIMM0
1
DDR4-2133,
1866, 1600
Empty
Quad-rank+
2
DDR4-1866,
1600
Quad-rank+
Quad-rank+
40
42
