No. Pin Description
SENSOR Loadcell / Speed Sensor Port
LOADCELL Loadcell
Connection Mode 6-Wire
4-Wire
[Default Set]
1 SEN+ Feedback Voltage +.
2 SEN- Feedback Voltage -.
3 SIG- Weighing Signal [mV]Input -. Weighing Signal [mV]Input -.
4 SIG+ Weighing Signal [mV]Input +. Weighing Signal [mV]Input +.
5 EXC- Excitation Voltage -. Excitation Voltage -.
6 EXC+ Excitation Voltage + [DC10V]. Excitation Voltage + [DC10V].
7 SHD Shield Ground. Shield Ground.
SPEED
Speed Sensor
3-Wire
[NPN Open-collector Output Type]
2-Wire Tachogenerator
8 VS- Voltage Output -. Pulse Signal Input -.
9 SIN Pulse Signal Input. Pulse Signal Input +.
Sine Wave Signal Input
Terminal 1.
10 VS+ Voltage Output + [DC12V].
Sine Wave Signal Input
Terminal 2.
POWER DC24V[±20%] Power Input Port
1 DC- DC Input -.
2 DC+ DC Input +.
The shell should be grounded directly to avoid electric shock.
