6.3.6 Speed Parameters
No. Parameter Range Default Set
P400
Decimal
(Speed Decimal Point)
0: o
1: o.o
2: o.oo
3: o.ooo
2
P401 Speed Range 0.100~5.000m/s 3.000
P402
Speed Upper
(Speed Upper Limit)
(0.0~100.0)% Speed Range 100.0%
P403
Speed Lower
(Speed Lower Limit)
(0.0~100.0)% Speed Range 0.0%
P404 SpeedFilter 1~200 10
P405 SpeedSource
0: Ext. Speed (Weighing by the external speed)
1: Int. Speed1 (Weighing by the internal speed)
2: Int. Speed2 (Connect a normally open switch
related to the running state of the weighing belt
between the terminals ‘SIN’ and ‘VS-’. Switch ON
with Belt’s Running: Weighing by the internal speed;
Switch OFF with Belt’s Stopping: Stop weighing)
3: Int. Speed3 (Weighing by the internal speed while
the external speed pulse inputting)
Note: If a DI signal is defined as ‘1: Weighing’, then
o
nly when this DI turns on, the weighing process is
allowed.
0
P406
Int. Speed
(Internal Speed)
0.001~5.000m/s 0.500
P407 Pulse Upper
0.1~3.0kHz
Speed Pulse Frequency Upper Limit: if the frequency
of speed pulse exceeds this set value, the speed pulse
will be invalid.
1.0
