6.3.2 Extra Scale Parameters
No.
Parameter
Range
Default
Set
P110
Cal. Revs
(Calibration Revolutions)
1~99R (1R=1 Belt Length) 3
P111 ChainWeight
0.1~1000.0kg/m
([P107] Scale Unit = kg)
Chain Weight for Span Calibration
10.0
0.1~1000.0g/m
([P107] Scale Unit = g)
P112 HangWeight
0.1~1000.0kg
([P107] Scale Unit = kg)
Hanging Weight for Span Calibration
10.0
0.1~1000.0g
([P107] Scale Unit = g)
P113
WeighLength
0.001~50.000m
1.000
P114 Cal.Current
4.00~20.00mA
Control Current for System Calibration
12.00
P115
Zero Track
(Zero Tracking Permission)
0: OFF; 1: ON 0
P116
Track Range
(Zero Tracking Range)
±(0~10%) × [P302] Flow Range ±5%
P117
Zero Adjust
(Zero Adjusting Range)
±(0~10%) × [P104] Zero Value ±5%
P118 ZeroRefresh
0: RAM (Only Refresh RAM Zero Value)
1: FLASH/RAM (Refresh Original Zero Value)
0
P119 Breakpoint1
0~[P120] (AD Value: 0~60000)
Breakpoint1 of Segmenting Span Correction
18000
P120 Breakpoint2
[P119]~Max. AD Value (60000)
Breakpoint2 of Segmenting Span Correction
42000
P121 Cor. Coeff1
0.500~2.000; Span Correction Coefficient of AD
Value Linear Segment 1: 0~[P119]
1.000
P122 Cor. Coeff2
0.500~2.000; Span Correction Coefficient of AD
Value Linear Segment 2: [P119]~[P120]
1.000
P123 Cor. Coeff3
0.500~2.000; Span Correction Coefficient of AD
Value Linear Segment 3: [P120~Max. AD Value
1.000
P124
Cal. Add (Totalizing While
Calibrating)
0: OFF
1: ON [In the process of ‘Load Calibration’,
the inputted actual weight value will be added to
Totalized Weight]
0
P125
Neg. Add
(Negative Totalizing)
0: OFF [The negative variance of Totalized
Weight will be ignored]
1: ON
1
