suprema FaceStation 2 - Technical Product Specifications

Product specifications
28
Product specifications
Category Feature Specification
Credential
Biometric
Face
RF Option
•
FS2-D: 125kHz EM & 13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa, NFC
• FS2-AWB: 125kHz EM, HID Prox & 13.56Mhz MIFARE, MIFARE Plus, DESFire/EV1, FeliCa,
iCLASS SE/SR, NFC, BLE
RF read range
*
MIFARE/DESFire/iCLASS : 50 mm / EM/HID Prox/Felica: 30 mm, BLE: 50 mm
LFD
Supported
General
CPU
1.4 GHz Quad Core
Memory
8GB Flash + 1GB RAM
LCD type
4” color TFT touch
LCD resolution
800 x 480
Sound
24 bit/Voice DSP (echo cancel)
Operating temperature
-20 °C - 50 °C
Storage temperature
-40 °C - 70 °C
Operating humidity
0% - 80%, non-condensing
Storage humidity
0% - 90%, non-condensing
Camera type
CMOS
Camera resolution
720 x 480
Camera angle
Visual Lens: Diagonal 92.7°
IR Lens: Diagonal 58°
Dimension (W x H x D)
141 mm x 164 mm x 125 mm
Weight
Device: 628 g
Bracket: 74 g (Including washer and bolt)
Certificates
CE, FCC, KC, RoHS, REACH, WEEE
Capacity
Max. User (1:1)
30,000
Max. User (1:N)
3,000
Max. Template (1:1)
900,000
Max. Template (1:N)
90,000
Max. Text Log
5,000,000
Max. Image Log
50,000
Interface
Wi-Fi
Supported (Built-in, IEEE802.11 b/g)
Ethernet
Supported (10/100/1000 Mbps, auto MDI/MDI-X)
RS-485
1ch Host or Slave (Selectable)
Wiegand
1ch Input, 1ch Output
TTL input
1ch Input
Relay
1 Relay
USB
USB 2.0 (Host)
Tamper
Supported
Electrical
Power
Voltage: 12 VDC
Current: Max. 2.5 A
Switch input VIH
Min.: 3 V
Max.: 5 V
Switch input VIL
Max.: 1 V
Switch Pull-up resistance
4.7 kΩ (The input pots are pulled up with 4.7 kΩ.)
Wiegand output VOH
More than 4.8 V
Wiegand output VOL
Less than 0.2 V
Wiegand output Pull-up resistance
Internally pulled up with 1 kΩ
Relay
Voltage: Max. 30 VDC
Current: 1 A, Max. 2 A
* RF read range will vary depending on installation environment.
