Surefire PumpRight D70 - Page 29

Wire 18AWG
unless otherwise
specified
Final Cable for SureFire Liquid Pump System (pwm, flow, pres., pump rpm, fill flow)
207-3462Y1
10/31/2016
Brandon Cavenee207-3462Y1
Final Cable for SureFire Liquid Pump System (pwm, flow, pres.,
pump rpm, fill flow)
Part No:
Description:
Drawn By:
Last Edit
Date:
27
Copyright 2016 SureFire Ag Systems, Reproduction or other use of drawing
without express written permission from SureFire Ag Systems is forbidden
Revision
A-01
1
2
3
4
5
6
+12V DC
Flow Signal
GND
Pressure
PWM (+)
PWM (-)
RED
BLK
BLU
PUR
YEL
DRK BLU
1
GND
+12V
AMP SUPER SEAL TOWER 3-PIN
BLK
RED
2
Flowmeter
3
Signal
BLU
PWM
A
150 MP Tower 2-PIN
B
PWM +
PWM -
YEL
GRN
Pressure
A
150 MP Shroud 3-pin
B
C
Signal
+12V
GND
PUR
RED
BLK
DEUTSCH 12-pin
DT04-12P
Pump
7
8
Include Dust CAP
1
GND
+12V
AMP SUPER SEAL TOWER 4-PIN
BLK
RED
2
Fill Flowmeter
3
Signal
DRK BLU
4
Open
ORG
A
GND
+12V
WP TOWER 3-PIN
B
C
Signal
Pump RPM
RED
BLK
9
10
11
12
Fill Flow
Pump RPM
Bin Level
Open
Section 1
Section 2
Include Dust CAP
Include Dust CAP
GRN
ORG
SureFire Ag Systems
