Surefire PumpRight D70 - Page 31

Wire18AWG
unlessotherwise
specified
12‐pinFinalCableforBasicDryFertilizerSystem(pwm,meterrpm,auxrpm,binlevel)
207‐3492Y2
2/10/2017
BrandonCavenee,Y2‐MAW207‐3492Y2
12‐pinFinalCableforBasicDryFertilizerSystem(pwm,meter
rpm,auxrpm,binlevel)
PartNo:
Description:
DrawnBy:
LastEdit
Date:
29
Copyright2016SureFireAgSystems,Reproductionorotheruseofdrawing
withoutexpresswrittenpermissionfromSureFireAgSystemsisforbidden
Revision
A‐02
1
2
3
4
5
6
+12VDC
FlowSignal
GND
Pressure
PWM(+)
PWM(‐)
RED
BLK
BLU
YEL
PWM
A
150MPTower2‐PIN
B
PWM+
PWM‐
YEL
GRN
MeterRPMSensor
A
B
C
+12V
GND
Signal
RED
BLK
BLU
DEUTSCH12‐pin
DT04‐12P
Pump
7
8
ORG
A
GND
+12V
WPTOWER3‐PIN
B
C
Signal
Aux.RPM,Motor,
Spinner,Fan
RED
BLK
9
10
11
12
FillFlow
PumpRPM
BinLevel
Open
Section1
Section2
GRN
ORG
WPSHROUD3‐PIN
150MPTOWER3‐PIN
BinLevelSensor
A Signal
B+12v
CGnd
ORG/WHT
ORG/WHT
RED
BLK
SureFire Ag Systems
