396-3815Y1 SureFire PumpRight for Raven RCM 39 Revised 01/16/2018
Model D70 - 2 Diaphragms
Fertilizer Flow
(GPM)
Pump Speed
(rpm)
Hydraulic Oil
Flow (GPM)
5 156 2.9
10 313 5.8
15 469 8.6
Model D115 - 3 Diaphragms
Fertilizer Flow
(GPM)
Pump Speed
(rpm)
Hydraulic Oil
Flow (GPM)
5 94 1.8
10 189 3.5
15 283 5.2
20 377 6.9
25 472 8.6
Model D160 - 4 Diaphragms
Fertilizer Flow
(GPM)
Pump Speed
(rpm)
Hydraulic Oil
Flow (GPM)
10 135 2.5
20 270 5.0
30 405 7.5
35 473 8.7
Model D250 - 6 Diaphragms
Fertilizer Flow
(GPM)
Pump Speed
(rpm)
Hydraulic Oil
Flow (GPM)
10 86 1.6
20 172 3.2
30 258 4.8
40 343 6.4
50 429 8.0
55 472 8.6
PumpRight Hydraulic Oil Flow Requirements
(Requirements for 4.0 CID Motor—standard SureFire motor beginning in 2016—
Earlier motor was 4.9 CID which uses 20% more oil)
Setting Tractor Hydraulic Remote Speed
PumpRight pumps require a constant hydraulic oil
flow from the tractor. The amount of oil needed
varies with pump size and speed. The chart at right
shows the necessary oil flow for each pump model at
varying fertilizer flows.
Use this procedure to determine the correct setting on
your tractor hydraulic flow.
1. Run the fertilizer system in the field at the
maximum rate and ground speed.
2. Turn down the hydraulic flow slowly while
watching the pump flow (Volume / Minute).
3. Observe when the Volume / Minute begins to
drop.
4. Turn the hydraulic flow back up slightly.
This setting will provide the Pump Right pump just
enough oil for your application rate.
If running with the bypass open (only recommended
when 2 motors are operated in series) this process
will minimize the oil circulated in the bypass loop,
leaving more oil flow for other hydraulic functions.
