Surefire PumpRight D70 - Page 63

REF. PART DESCRIPTION QTY.
NO. NUMBER REQ’D
86 9910-550920 Flange 1
87 9910-550950 M10 x 25 Bolt 3
88 9910-180030 Bolt 1
89 9910-620561 O-ring 1
90 9910-621000 Gear cap 1
91 9910-550930 Gear 1
92 9910-620950 Gasket 1
93 9910-1140370 Oil plug & O-ring 1
94 9910-1980740 Plug 3
95 9910-740290 O-ring 3
96 9910-621010 Bolt 4
97 9910-620960 Gear box 1
98 9910-540290 M8 x 25 Bolt 4
99 9910-651000 Bolt 4
100 9910-881090 Key 1
101 9910-961800 Seal ring 1
102 9910-961790 Circlip 1
103 9910-320240 Circlip 2
104 9910-961780 Bearing 1
105 9910-621660 Pinion 1
106 9910-620990 Bearing 1
Model D115
REF. PART DESCRIPTION QTY.
NO. NUMBER REQ’D
1 9910-580013 Pump body with bolts 1
2 9910-580150 Manifold 1
3 9910-550101 DX Right head 2
4 9910-550102 SX Left head 1
5 9910-180152 Nut 3
8 9910-550080 Diaphragm (Buna) Optional 3
8 9910-550085 Diaphragm (Desmopan) Standard 3
9 9910-580110 Sleeve (D115) 3
9 9910-580350 Sleeve (D135) 3
10 9910-500260 Piston ring 3
12 9910-580120 Piston 3
13 9910-380300 Pin 3
14 9910-380080 Pin ring 6
15 9910-580140 Connecting rod 3
16 9910-320030 O-ring 6
17 9910-759051 Complete valve 6
18 9910-540541 Ring nut 1
19 9910-390291 O-ring 7
20 9910-540530 Threaded adapter 1
21 9910-390271 Nut 3
23 9910-580050 Gasket 1
25 9910-580180 Accumulator manifold 1
26 9910-550190 Accumulator diaphragm 1
27 9910-559204 Accumulator head 1
28 9910-550300 Air valve 1
29 9910-650542 O-ring 1
30 9910-550680 M8 x 20 Bolt 4
31 9910-200391 Retainer ring 1
32 9910-550470 Gasket retainer 1
33 9910-550070 Spacer ring 1
34 9910-550060 Roller bearing 1
35 9910-550170 Shaft (D115) 1
36 9910-580470 Connecting rod ring 2
37 9910-551040 M10 x 55 Bolt 12
38 9910-550310 Roller bushing 1
46 9910-550340 Threaded adapter 1
47 9910-550350 O-ring 1
48 9910-550242 Ring nut 1
49 9910-550370 Elbow 1" 1
50 9910-540550 Elbow 1-1/2" 1
52 9910-250310 O-ring 1
53 9910-550491 Seal ring 1
54 9910-650920 O-ring 1
55 2406-0023 Oil drain plug 1
56 9910-330173 Plug 1
57 9910-589200 DX Right valve retainer w/plug/o-ring 2
58 9910-580072 SX Left valve retainer 1
59 9910-1500350 Shield 1
60 9910-550332 Washer 2
61 9910-320621 Washer 5
62 9910-740290 O-ring 1
63 9910-580330 Shaft (D135) 1
64 9910-580370 Plate 3
65 9910-580360 Diaphragm bolt 3
66 9910-250310 O-ring 1
69 9910-200233 Washer 2
77 9910-180101 O-ring 1
78 9910-850851 M6 x 30 Bolt 2
79 9910-620472 M10 x 20 Bolt 3
80 9910-550175 Shaft 1
81 9910-390180 O-ring 1
82 9910-1040310 Oil sight glass 1
83 9910-650920 O-ring 1
84 9910-1040322 Black oil tank cap 1
85 9910-580230 O-ring 1
107 9910-2240110
1
108 9910-2240100
Nut
Stud
1
109 9910-580371 Plate
1
61
