Surefire PumpRight D70 - Page 67

Model D250
REF. PART DESCRIPTION QTY.
NO. NUMBER REQ’D
1 9910-750071 Bolt 4
2 9910-750200 Base 1
3 9910-750740 O-ring 2
4 9910-751070 Suction Manifold 1
5 9910-380242 Nut 26
6 9910-751350 Head 6
7 9910-680070 O-ring 12
8 9910-759051 Complete valve 12
9 9910-200390 Retainer ring 2
10 9910-750170 Crankshaft 1
11 9910-750110 Sleeve 6
12 9910-750061 M12 x 65 Bolt 20
13 9910-680350 M8 x 35 Bolt 2
14 9910-1040060 O-ring 1
15 9910-750057 Black oil tank cap 1
16 9910-750030 Oil sight glass 1
17 9910-750040 Gasket 1
18 9910-751300 Pump body 1
19 9910-851360 O-ring 1
20 9910-680020 Shaft support 1
21 9910-160672 M10 x 25Bolt 6
22 9910-751130 Threaded adapter 1
23 9910-751140 O-ring 1
23A 9910-390290 O-ring 1
24 9910-750670 Ring nut 1
25
9910-750660
1
26 9910-550085 6
26A 9910-550080
Elbow 1 1/2" HB
Diaphragm (Desmopan) Standard
Diaphragm (Buna) Optional
6
27 9910-500260 Piston ring 6
28 9910-750122 Piston 6
29 9910-751080 Manifold 1
30 9910-160700 Pin 6
31 9910-160691 Pin ring 2
32 9910-750140 Connecting rod 6
33 9910-750090 Roller bearing 2
34 9910-750130 Connecting rod ring 2
35 9910-540040 Spacer washer 2
36 9910-230350 Bearing 2
37 9910-160740 Seal ring 2
38 9910-380243 Washer 26
39 9910-250143 Washer 4
40 9910-850251 M8 x 12 Bolt 6
41 9910-1500350 Shield 2
42 9910-750850 1
43 9910-750710 1
46 9910-620232 1
47 9910-550190
Elbow 2" HB
Ring nut
Accumulator head
Accumulator diaphragm
1
48 9910-680180 Accumulator body
49 9910-621781 M8 x 40 Bolt 8
51 9910-390290 O-ring 1
52 9910-180101 O-ring 2
53 9910-330173 Plug 2
54 9910-650542 Gasket 1
55 9910-180020 Air valve 1
56 9910-750370 Elbow 1
57 9910-880581 Oil drain plug 1
58 9910-390314 Washer 6
59 9910-2240110 Diaphragm nut 6
60 9910-751250 Retainer washer 6
61 9910-880820 Washer 1
62 9910-2240100 Diaphragm stud 6
65
