F0-01=0 Operating panel command channel
F1-11=1or2
（1：Static tuning .
2：Complete tuning , must separate the load from motor）
note:thedisplay TUNE that is flashing ，make sure the output
circuit is looped，Then press the RUN button to perform the
parameter tuning .
Complete tuning ，the motor is actionless，
but engender electromagnetism noises 。
Then we can get the Parameter：
F1-06、F1-07、F1-08.
F1-09、F1-10 is automatically count
Static tuning
Complete tuning
Complete tuning .Motor will running about
one min.we can get the paremeter ：
F1-06、F1-07、F1-08、F1-09、F1-10。
F1-01、F1-02、F1-03、F1-04、F1-05
set according to the nameplate parameters of the motor
After tuning，recover the paremeter F0-01=1
F0-01=0
Set as operation panel control
Fig 6-1 Asynchronous motor tuning ow chart
Automatically tuning step of permanent-magnet synchronous motor is following:
First, set F0-01 as 0: the control mode selects the operating panel command channel.1)
Set F1-00 as 0 by actual motor type: synchronous motor. Then set F1-01、F1-02、2)
F1-03、F1-04、F1-05 according to the nameplate parameters of motor.
Completely separate the motor from the load (ro
pe), the parameter F1-11 selects 3)
2(complete tuning). Then press RUN of the operation panel and the motor can
automatically run. The controller automatically counts the F1-06 encoder initialized angle.
The motor tuning is then over. Operate the tuning more than 3 times, then compare F1-06
encoder initialized angle already gained, make sure the error is within the range of ±5°.
