Suzuki 125 - Page 3

2 RV125K7 (’07-MODEL)
RV125K7 (’07-MODEL)
CONTENTS
FUEL SYSTEM .................................................................................................. 83
FUEL TANK .............................................................................................. 83
FUEL LEVEL INDICATOR CHECK RELAY ............................................ 85
FUEL FILTER ........................................................................................... 86
THROTTLE BODY.................................................................................... 87
WIRING DIAGRAM ............................................................................................ 93
CABLE AND HOSE ROUTING.......................................................................... 94
SPECIAL TOOLS............................................................................................... 97
TIGHTENING TORQUE ..................................................................................... 97
SERVICE DATA................................................................................................. 98
COUNTRY AND AREA CODES
The following codes stand for the applicable country(-ies) and area(-s).
MODEL CODE COUNTRY or AREA EFFECTIVE FRAME NO.
RV125
E-02
E-19
U.K.
E.U.
JS1BT111200101909 –
JS1BT111100111063 –
