RV125K7 (’07-MODEL) 43
DTC No.
DETECTED
ITEM
DETECTED FAILURE CONDITION CHECK FOR
23
TO sensor The sensor voltage should be the fol-
lowing for 2 sec. and more, after igni-
tion switch is turned ON.
0.2 V sensor voltage < 4.6 V
In other than the above value, 23
(P1651) is indicated.
TO sensor, lead wire/coupler
connection
P1651
H
Sensor voltage is higher than specified
value.
TO sensor circuit shorted to
VCC or ground circuit open
L
Sensor voltage is lower than specified
value.
TO sensor circuit open or
shorted to ground or VCC circuit
open
24
Ignition
signal
CKP sensor (pick-up coil) signal is pro-
duced, but signal from ignition coil is
interrupted 10 times or more continu-
ously. In this case, the code 24
(P0351) is indicated.
Ignition coil, wiring/coupler con-
nection, power supply from the
battery
P0351
32
Fuel injector CKP sensor (pickup coil) signal is pro-
duced, but fuel injector signal is inter-
rupted 10 times or more continuously.
In this case, the code 32 (P0201) is
indicated.
Primary fuel injector, wiring/cou-
pler connection, power supply to
the injector
P0201
40
ISC valve When the ISC operation voltage
remains at 1.0 V or lower continuously
for 2 sec. or longer.
Idle speed is higher than the normal
condition.
ISC valve circuit open or shorted
to ground
Power source circuit open ISC
valve is fixed to full open
Disconnected ISC valve hose
P0505
42 Ignition
switch
Ignition switch signal is not input to the
ECM.
Ignition switch, lead wire/coupler,
etc.P1650
44
HO2 sensor HO2 sensor output voltage is not input
to ECM during engine operation and
running condition.
(Sensor voltage < 0.60 V)
In other than the above value, 44
(P0130) is indicated.
HO2 sensor circuit open or
shorted to ground
P0130
44
The Heater can not operate so that
heater operation voltage is not supply
to the oxygen heater circuit, 44
(P0135) is indicated.
HO2 sensor lead wire/coupler
connection
Battery voltage supply to the
HO2 sensor
P0135
