4-12 FI SYSTEM DIAGNOSIS
FI SYSTEM PARTS LOCATION
Intake air temperature sensor (IATS) Throttle position sensor (TPS)
Secondary throttle position sensor (STPS) Secondary throttle valve actuator (STVA)
Exhaust control valve actuator (EXCVA) Fuel pump relay (FP relay)
Fuel pump (FP) Crankshaft position sensor (CKPS)
Heated oxygen sensor (HO2S) Driving mode selection switch (DMSS)
Intake air pressure sensor (IAPS)
ECM

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSX-R1000 2007 and is the answer not in the manual?

Suzuki GSX-R1000 2007 Specifications

General IconGeneral
Engine Type4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement999 cc
Bore x Stroke73.4 mm x 59.0 mm
Compression Ratio12.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
Transmission6-speed constant mesh
Front SuspensionInverted telescopic, coil spring, oil damped
Front BrakesDual hydraulic disc
Rear BrakesSingle hydraulic disc
Seat Height810 mm
Lubrication SystemWet sump
StarterElectric
Final DriveChain
Ground Clearance130 mm
Rear SuspensionLink type, coil spring, oil damped
Front Tire120/70ZR17M/C (58W)
Rear Tire190/50ZR17M/C (73W)
Overall Length2045 mm (80.5 in)
Overall Height1, 130 mm
Overall Width720 mm (28.3 in)
Wheelbase1, 405 mm
Curb Weight203kg
