Suzuki GSX-R1000 2007 Service Manual

CHASSIS 8-77


BRAKE PAD REPLACEMENT
• Remove the pad mounting pin .
• Remove the caliper mounting bolt .
• Remove the brake pads with the rear caliper pivoted up.
• Clean up the caliper especially around the caliper piston.

• Install the new brake pads.
" Pad mounting pin: 16 N·m (1.6 kgf-m, 11.5 lb-ft)
Brake caliper mounting bolt: 18 N·m (1.8 kgf-m, 13.0 lb-ft)
NOTE:
After replacing the brake pads, pump the brake pedal a few
times to set the brake parts correctly and then check the brake
fluid level.
* This brake system is filled with an ethylene glycol-based DOT 4 brake fluid. Do not use mix
different types of fluid such as silicone-based or petroleum-based.
* Do not use any brake fluid taken from old, used or unsealed containers. Never reuse brake
fluid left over from the last servicing or stored for long periods.
* When storing the brake fluid, seal the container completely and keep away from children.
* When replenishing brake fluid, take care not to get dust into fluid.
* When washing brake components, use fresh brake fluid. Never use cleaning solvent.
* A contaminated brake disc or brake pad reduces braking performance. Discard contaminated
pads and clean the disc with high quality brake cleaner or neutral detergent.
Handle brake fluid with care: The fluid reacts chemically with paint, plastics, rubber materials
etc. and will damage then severely.
* Do not operate the brake pedal with the pads
removed.
* Replace the brake pads as a set, otherwise braking
performance will be adversely affected.

Suzuki GSX-R1000 2007 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	999 cc
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	810 mm
Lubrication System	Wet sump
Starter	Electric
Final Drive	Chain
Ground Clearance	130 mm
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/50ZR17M/C (73W)
Overall Length	2045 mm (80.5 in)
Overall Height	1, 130 mm
Overall Width	720 mm (28.3 in)
Wheelbase	1, 405 mm
Curb Weight	203kg
