Suzuki GSX-R1000 2007 Service Manual

8-72 CHASSIS
MASTER CYLINDER REMOVAL AND
DISASSEMBLY
• Drain the brake fluid. (8-67)
• Disconnect the front brake light switch lead wires .
• Place a rag underneath the union bolt  on the master cylin-
der to catch any split brake fluid. Remove the union bolt and
disconnect the brake hose.

• Remove the master cylinder by removing the master cylinder
bolts.
• Remove the reservoir cap , insulator , diaphragm  and
reservoir tank .
• Remove the brake switch  and brake lever .
Immediately and completely wipe off any brake fluid
contacting any part of the motorcycle. The fluid reacts
chemically with paint, plastics and rubber materials,
etc. and will damage them severely.

Suzuki GSX-R1000 2007 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	999 cc
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	810 mm
Lubrication System	Wet sump
Starter	Electric
Final Drive	Chain
Ground Clearance	130 mm
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/50ZR17M/C (73W)
Overall Length	2045 mm (80.5 in)
Overall Height	1, 130 mm
Overall Width	720 mm (28.3 in)
Wheelbase	1, 405 mm
Curb Weight	203kg
