Suzuki GSX-R1000 2007 Service Manual

5-4 FUEL SYSTEM AND THROTTLE BODY
FUEL TANK REMOVAL
• Lift and support the fuel tank. (5-3)
• Disconnect the fuel pump lead wire coupler .
• Disconnect the fuel tank drain hose  and fuel tank breather
hose  (Except for E-33).
• Place a rag under the fuel feed hose  and disconnect the
fuel feed hose from the fuel tank.

#
• Remove the fuel tank by removing the mounting bolt.
FUEL TANK INSTALLATION
• Installation is in the reverse order of removal.
When removing the fuel tank, do not leave the fuel
feed hose  on the fuel tank side.
Gasoline is highly flammable and explosive.
Keep heat, spark and flame away.

Suzuki GSX-R1000 2007 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	999 cc
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	810 mm
Lubrication System	Wet sump
Starter	Electric
Final Drive	Chain
Ground Clearance	130 mm
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/50ZR17M/C (73W)
Overall Length	2045 mm (80.5 in)
Overall Height	1, 130 mm
Overall Width	720 mm (28.3 in)
Wheelbase	1, 405 mm
Curb Weight	203kg
