Suzuki GSX-R1000 2007 Service Manual

CHASSIS 8-63
• Install the chain case  chain buffer  and rear fender .
INSTALLATION
Install the swingarm in the reverse order of disassembly and
removal, and pay attention to the following points:
SWINGARM PIVOT THRUST CLEARANCE ADJUSTMENT
Adjust swingarm pivot thrust clearance in the following procedure.
• Insert the swingarm pivot shaft and tighten it to the specified
torque.
 09944-28320: Hexagon socket (19 mm)
" Swingarm pivot shaft: 15 N·m (1.5 kgf-m, 11.0 lb-ft)
• Hold the swingarm pivot shaft and tighten the swingarm pivot
nut to the specified torque.
" Swingarm pivot nut: 100 N·m (10.0 kgf-m, 72.5 lb-ft)
• Tighten the swingarm pivot lock-nut to the specified torque
with the special tool.
 09940-14940: Swingarm pivot thrust adjuster socket
wrench
" Swingarm pivot lock-nut: 90 N·m (9.0 kgf-m, 65.0 lb-ft)

Suzuki GSX-R1000 2007 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	999 cc
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	810 mm
Lubrication System	Wet sump
Starter	Electric
Final Drive	Chain
Ground Clearance	130 mm
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/50ZR17M/C (73W)
Overall Length	2045 mm (80.5 in)
Overall Height	1, 130 mm
Overall Width	720 mm (28.3 in)
Wheelbase	1, 405 mm
Curb Weight	203kg
