Suzuki GSX-R1000 2007 Service Manual

CHASSIS 8-3
EXTERIOR PARTS
FASTENER REMOVAL AND INSTALLATION
FASTENER (Type A)
Removal
• Depress the head of fastener center piece .
• Pull out the fastener .
Installation
• Let the center piece stick out toward the head so that the
pawls  close.
• Insert the fastener into the installation hole.
NOTE:
To prevent the pawl  from damage, insert the fastener all the
way into the installation hole.
• Push in the head of center piece until it becomes flush with
the fastener outside face.
FASTENER (Type B)
Removal
• Pry up the head of fastener center piece  with a screw
driver.
• Pull out the fastener .

Suzuki GSX-R1000 2007 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	999 cc
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	810 mm
Lubrication System	Wet sump
Starter	Electric
Final Drive	Chain
Ground Clearance	130 mm
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/50ZR17M/C (73W)
Overall Length	2045 mm (80.5 in)
Overall Height	1, 130 mm
Overall Width	720 mm (28.3 in)
Wheelbase	1, 405 mm
Curb Weight	203kg
