SERVICING INFORMATION 10-3
TROUBLESHOOTING
FI SYSTEM MALFUNCTION CODE AND DEFECTIVE CONDITION
(4-30 to -35)
ENGINE
Complaint Symptom and possible causes Remedy
Engine will not start
or is hard to start.
Compression too low
1. Valve clearance out of adjustment
2. Worn valve guides or poor seating of valves
3. Mistiming valves
4. Excessively worn piston rings
5. Worn-down cylinder bores
6. Too slowly starter motor cranks
7. Poor seating of spark plugs
Plug not sparking
1. Fouled spark plugs
2. Wet spark plugs
3. Defective ignition coil
4. Defective CKP sensor
5. Defective ECM
6. Open-circuited wiring connections
No fuel reaching the intake manifold
1. Clogged fuel filter or fuel hose
2. Defective fuel pump
3. Defective fuel pressure regulator
4. Defective fuel injector
5. Defective fuel pump relay
6. Defective ECM
7. Open-circuited wiring connections
Incorrect fuel/air mixture
1. TP sensor out of adjustment
2. Defective fuel pump
3. Defective fuel pressure regulator
4. Defective TP sensor
5. Defective CKP sensor
6. Defective IAP sensor
7. Defective ECM
8. Defective ECT sensor
9. Defective IAT sensor
10. Defective AP sensor
11. Clogged ISC valve air passage way
Adjust.
Repair or replace.
Adjust.
Replace.
Replace.
See electrical section.
Retighten.
Clean.
Clean and dry.
Replace.
Replace.
Replace.
Repair or replace.
Clean or replace.
Replace.
Replace.
Replace.
Replace.
Replace.
Check and repair.
Adjust.
Replace.
Replace.
Replace.
Replace.
Replace.
Replace.
Replace.
Replace.
Replace.
Repair or replace.

Suzuki GSX-R1000 2007 Specifications

General

Engine Type	4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement	999 cc
Bore x Stroke	73.4 mm x 59.0 mm
Compression Ratio	12.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	6-speed constant mesh
Front Suspension	Inverted telescopic, coil spring, oil damped
Front Brakes	Dual hydraulic disc
Rear Brakes	Single hydraulic disc
Seat Height	810 mm
Lubrication System	Wet sump
Starter	Electric
Final Drive	Chain
Ground Clearance	130 mm
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W)
Rear Tire	190/50ZR17M/C (73W)
Overall Length	2045 mm (80.5 in)
Overall Height	1, 130 mm
Overall Width	720 mm (28.3 in)
Wheelbase	1, 405 mm
Curb Weight	203kg
