The parts listed below can be removed and reinstalled without removing the
to the page listed in this section for removal and reinstallation instructions.
ENGINE LEFT SIDE
See page
Secondary bevel gear case cover
...... 3-3
Secondary bevel gear case ...........
3-14
Gearshift lever ...................
3-3
Generator cover ..................
3-l 2
Generator rotor ..................
3-l 3
Neutral indicator switch body
....... 3-14
Generator stator ..................
7-7
Pick-up coil .....................
7-7
Secondary driven bevel gear
......... 3-15
Water pump case .................
3-3
Water pump assembly ..............
5-7
ENGINE CENTER
See page
Radiator
........................
3-3
Exhaust pipe and muffler
...........
3-3
Oil filter
........................
3-12
Carburetor
......................
3-3
Oil sump filter
...................
3-12
Oil pressure switch
................
3-l 7
Starter motor assembly
............
3-l 2
engine from the frame. Refer
ENGINE RIGHT SIDE
See page
Clutch cover . . . . . . . . . . . . . . . . . . . . . . .
3-9
B
Clutch pressure, drive and
!z
driven plates . . . . . . . . . . . . . . . . . . . . . 3-9
d
Oil pump driven gear . . . . . . . . . . . . . . . .
3-10
v)
Oil pump drive chain . . . . . . . . . . . . . . . . 3-10 3
Primary drive gear
. . . . . . . . . . . . . . . . . .
3-10
Oil pump assembly . . . . . . . . . . . . . . . . . .
3-11
z
Gearshift shaft . . . . . , . . . . . . . . . . . . . . .
0
3-11 <
$
ii
s
?
2
m
z
4
m
z
