Sveaverken F100 - Chapter 1 Product Overview; Main Components; Control Terminal Ports

1 ©2022 Sveaverken. All rights reserved.
Sveaverken F100 Auto Steer System Software User Manual
Chapter 1 Product Overview
1 Main Components
Figure 1.
Main components
1
Control terminal
Serves as the human-machine interface, and vehicle control
and communication terminal.
2
Electric steering wheel
Consists of a steering motor and a steering wheel, and
controls the vehicle steering.
3
GNSS receiver
Receives satellite signals to obtain the vehicle location.
2 Control Terminal Ports
Figure 2.
Control terminal ports
!
"
#
