48 A-96.250.531 / 300617
AMI Oxytrace QED
Maintenance
7 Place the electrode slightly tilted
into the flow cell, so that the sensor
cap rests on the rim for the O-ring.
A Tilted sensor
B Flow cell
8 Press [Enter] to start the calibra-
tion measurement.
The saturation should reach
100%, the saturation current
should be about 22
A to 33
A.
If the measuring values are not
stable during the measuring
period, the calibration will be
discarded.
9 Press [Enter] to confirm the cali-
bration.
3.1.5
Calibration
Place the electrode into
the wet flow cell at
a slightly tilted angle.
<Enter> to continue
A
B
3.1.1
Calibration
Saturation 98.7 %
Sat. Current 32
A
Progress
3.1.1
Calibration
Saturation 98.7 %
Sat. Current 32
A
Calibration Successful
