Swann AMI Oxytrace - Calibration History; Miscellaneous; QA History; Sample

70 A-96.250.531 / 300617
AMI Oxytrace QED
Program List and Explanations
2.2.1.4 Cal. History
Review the diagnostic values of the last calibration of the oxygen
sensor. Max. 64 data records are memorized.
Number: Calibration counter.
Date, Time: Date and time of the calibration.
Sat. Current: Saturation current at that time of calibration.
Air pressure: Air pressure at that time of calibration.
2.2.2 Miscellaneous:
2.2.2.1 Case Temp: Shows the actual temperature in °C inside the trans-
mitter.
Air pressure: Shows the actual air pressure in hPa
2.2.3 QA History
Review QA values (Number, Date, Time, Deviation oxygen, Devia-
tion Temperature, Status of QA check) of the last quality assurance
procedures.
2.3 Sample
2.3.301 Sample ID: Shows the assigned sample identification. This
identification is defined by the user to identify the location of the
sample
Temperature: Shows temperature in °C.
(Nt5K): Shows raw value of the temperature in 
Sample Flow: Shows the sample flow in l/h
(Raw value) Shows the sample flow in Hz
2.4 I/O State
Shows actual status of all in- and outputs.
2.4.1
2.5 Interface
2.5.1 Only available if optional interface is installed.
Shows the programmed communication settings.
Alarm Relay: Active or inactive.
Relay 1 and 2: Active or inactive.
Input: Open or closed.
Signal Output 1 and 2: Actual current in mA
Signal Output 3: Actual current in mA (if option is installed)
