80 A-96.250.531 / 300617
AMI Oxytrace QED
Program List and Explanations
5.3.1.2.2 Alarm High: If the measuring values rises above the programmed
value E009 will be issued.
Range: 12–50 l/h
5.3.1.2.35 Alarm Low: If the measuring values falls below the programmed
value E010 will be issued.
Range: 8–11 l/h
5.3.1.3 Sample Temp.: Define at which sample temperature an alarm
should be issued.
5.3.1.3.1 Alarm High: If the measured value rises above the alarm high val-
ue, the alarm relay is activated and E007 is issued.
Range: 30–100 °C
5.3.1.3.25 Alarm Low: If the measured value rises above the alarm high value,
the alarm relay is activated and E008 is issued.
Range: -10 to + 20 °C
5.3.1.4 Alarm Saturation
5.3.1.4.1 Alarm High: If the measured value rises above the alarm high val-
ue, the alarm relay is activated and E003, is displayed in the mes-
sage list.
Range: 0.00 –200 %
5.3.1.4.25 Alarm Low: If the measured value falls below the alarm low value,
the alarm relay is activated and E004 is displayed in the message
list.
Range: 0.00 –200 %
5.3.1.4.35 Hysteresis: Within the hyst. range, the relay does not switch. This
prevents damage of relays contacts when the measured value fluc-
tuates around the alarm value.
Range. 0.00 –200 %
5.3.1.4.45 Delay: Duration, the activation of the alarm relay is retarded after
the measuring value has risen above/fallen below the programmed
alarm.
Range: 0–28‘800 Sec
5.3.1.5 Case Temp.
5.3.1.5.1 Case Temp. high: Set the alarm high value for temperature of elec-
tronics housing. If the value rises above the programmed value
E013 is issued.
Range: 30–75 °C
5.3.1.5.2 Case Temp. low: Set the alarm low value for temperature of elec-
tronics housing. If the value falls below the programmed value
E014 is issued.
Range: -10 to + 20 °C
