Equipment details
107
OHEAT 2: Thermostat tripped. To re-set,
disconnect 12V from the boiler and
connect again.
WINDO: Window open, the boiler stops for
gas. Gas operation in the boiler starts when
the window is closed. Electrical operation
functions. Check the vehicle instructions to see
whether this function is installed.
SERIAL: There is a connection fault between
boiler and panel. Normally, this is a mechanical
fault in the connection between the heater and
panel. To re-set, break the main current and
then start again.
19. EMERGENCY START
• Disconnect 12V and the cable to the panel on
the heater.
• Connect a cable between 2 and 9 in the
contact device (on the heater).
• Connect 12V to the heater.
Now the heater starts with gas and 1kW.
(Regulation of room temperature does not
function, constant pump operation)
TECHNICAL DATA
Measurements/Weights
Boiler height: 310mm
Boiler depth: 340mm
Boiler width: 510mm
Weight: 14kg (without fluid)
Gas Propane Butane
Output 1: 3.3kW 3.8kW
Consumption 245g/h 275g/h
Output 2: 5.5kW 6.4kW
Consumption: 405g/h 460g/h
Pressure: I3+ 28-30/37 mbar
I3B/P 30 mbar
Volume/Pressure/Temp
Liquid volume radiator water: 3.5 litre
Liquid volume warm water: 8.4 litre
Max pressure radiator water: 0.05MPa
(0.5 bar)
Max pressure warm water: 0.3MPa
(3.0 bar)
System temperature:
max 85°C
230V ~
Output element: 1 x 1050W
Output element (2 or 3kW): 1 x 2100W
12V DC
Current consumption: 1 amp (max)
Fuse: 3.15 amp+ / 3.15amp-
