Description
1. Display
2. Intuitive keyboard
3. Probe measuring indicator
4. Probe
5. Probe xing lever
6. Probe weight adjustement selector
7. Multi function key FCT
8. Ergonomic handle and battery cover
9. UP / DOWN button, progressive activation of measurement carriage speed
10. USB connector
11. Power or foot pedal input connector
12. Power or foot pedal input connector
13. RS232 connector
14. DC power and charge indicators
15. Battery cover xing screw location
Description of intuitive keyboard and display
16. Preset | Zero
17. Min | Max measuring mode key
18. Activation of extended functions and parameters key
19. Surface | diameter measuring modes key
20. Active reference selection key
21. ON | OFF key
22. Probe constant setting key
23. Unit indicators
24. Reference active indicator
25. Probe constant setting | display indicator
26. Keyboard locked indicator
27. Displayed value frozen until probe contacts again
28. RS232 | USB |
Bluetooth
®
transmission indicator
29. Diameter value indicator
30. Center value indicator in diameter/centerline mode
31. Low battery warning - charger must be connected
32. Min | Max mode active indicator
33. Min | Max mode active indicator
34. Diameter measuring mode indicator
35. Probe direction indicators
36. Deactivated corrections alert indicator
37. Preset input indicator
38.
Bluetooth
®
connection indicators
39. Buer full indicator (buer mode)
