18
Commands
Most of the Hi_Cal functions can be controlled by a computer
or a PLC by sending ASCII commands.
As a rule, the format of these commands consists of the rst 3 letters of the
corresponding command. Commands can be in upper or lower case, with or
without spaces.
Sending the command <?> corresponds to a data request.
Important: all commands must be followed by a CR (Carriage Return)
Command Correspond to Function
? Send the displayed DIA and
CEN value in diameter mode
A
AOFF0/1/ ? Auto OFF Automatic switch-o deac-
tivated (SBY00) / Activated
(SBYxx) / Polling
B
BAT ? Battery status (BAT1 = OK,
BAT0 = low battery)
BT0/1 BlueTooth
Bluetooth
®
module disabled
/ enabled
BTRST Resetting
Bluetooth
®
pairing
C
CEN? Request for printout of the
Center’s value
CFGSEP0/1/ ? DIACEN value separator
deactivated (CR) / activated
(;) / enquiry
CLE CLEar Resets the minimum and
maximum registers
D
DEL DELta Delta mode (maximum -
minimum)
DIA Diameter mode
DIA? DIAmeter Diameter value print request
DIF? Sending the dierence between
the last 2 measurements
E
EXT0-10 EXTernal contact See « Button FCT »
