30 - 36
6.3.2 Pro-Composer General Error Messages
System is not calibrated. A successful calibration is required before scanning.
In order to perform a component scan, the system must be calibrated. This is done using the Open
Calibration command of the Pro-Measure software.
filename Schematic contains non registered Feature Types.
A schematic was loaded which contained features not active on this Pro-Composer installation.
No more than X features of this type may be defined.
The number of measurements definable for a particular feature type is limited (normally to 9 or 99).
This constraint is due to the Label size of three.
No more than X measurements may be defined.
The maximum number of definable measurements for a schematic has been reached.
System is in use by another application.
The system is being used by another application for scanning/measuring. Either wait for the other
application to complete its task or stop the task.
Schematic has been successfully saved but the program cannot be compiled until the
Component Reference Position is set.
Although the Schematic has been saved, the Procal program cannot be generated for this
schematic until the 'Set Component Position' routine has been completed.
Failed to open filename file.
The selected file failed to load. This could be a general file access problem or because the file is
locked. The file or disc could be damaged or corrupt.
Failed to create filename file.
The selected file could not be created. This could be because you do not have the correct access
rights for the folder. It may also be because the file already exists and has read only attributes.
File filename is corrupt or not a Pro-Composer Schematic file.
A problem occurred trying to convert a DOS version schematic for use with this version of Pro-
Composer. This could also be caused if the schematic was created in a newer version of Pro-
Composer software.
