6.3.3 Pro-Composer Defining Measurements Error Messages
Measurement Zone(s) not suitable for Feature Type.
The zone doesn't contain the specified feature, or if it is a two zone intersection, the zones don't cause
an intersect point.
Standards Database Error. Insufficient Data.
A standard has been chosen, but not all the fields have been selected (turned green) on the
Standards Database page or the Measurement Properties dialog box..
Standards Database Error: Parameter name not in FeatureType name.
A Standards database table has been defined which tries to use a non-existent parameter in the
specified Feature Type.
Parameter out of range.
A specified parameter value is incorrect for the measurement.
Upper Limit must be greater then Lower Limit.
For Min-Max parameters, the max must be bigger than the min.
Label must be either 1 letter followed by 2 digits, or 2 letters followed by a digit.
Labels must be of the correct format.
Label already used.
Labels must be unique. You have chosen one that is already in use. The label in question could be
for a Sub Measurement Feature and so not visible on the schematic drawing.
