Installation 2 - 13

Mounting the Bracket on a Desktop

Figure 2-13

Mounting on a Desktop

NOTE If mounting to a thin surface, a reinforcing plate maybe required.

Nuts

Lock Washers

Cap Screws

Mounting Bracket

Mounting Surface

Flat Washers

Lock Washers

Flat Washers
