Symbol VC5090 - Adjusting the Keyboard

Installation 2 - 17
Figure 2-18 Keyboard Port
Adjusting the Keyboard
To adjust the keyboard:
1. Loosen the locking knobs.
Figure 2-19 Loosen Locking Knobs
2. Squeeze the quick release tabs.
Figure 2-20 Squeeze Quick Release Tabs
USB/Keyboard Connector
Keyboard Cable
