Symetrix 601 - Table 14. D E - Ess Processor; Table 15. Noise Reduction Processor; Table 16. Delay Processor

C-9
Rev 2.2, 10/31/94
Table 14. De-ess Processor
Offset Description Range Reference
dec hex dec
21 15 Mode 0: off
127: on
22 16 Absolute Threshold See Attn100 Table
23 17 Relative Threshold See Attn100 Table
24 18 Attack Time See Tc Table
25 19 Release Time See Tc Table
Table 15. Noise Reduction Processor
Offset Description Range Reference
dec hex
dec
26 1A Mode 0: off
127: on
27 1B Minimum Turnover Freq See Frequency Table
28 1C Reserved .
29 1D Absolute Threshold See Attn100 Table
30 1E Relative Threshold See Attn100 Table
31 1F Reserved
32 20 Reserved
Table 16. Delay Processor
Offset Description Range Reference
dec hex dec
33 21 Mode 0: off
127: on
34 22 Delay Line 1 Delay Time 0-127
0: 500 µs
127: 330 ms
See DelayTime Table
35 23 Delay Line 2 Delay Time 0-127
0: 500µS
127: 330ms
See DelayTime Table
36 24 Delay Line Rate of Change 0-127 See Tc Table
37 25 Cross Recirculation
Attenuation
0: pos 0 dB
64: off
127: neg 0 dB
See Delay Feedback
Table
38 26 Filter Frequency 0-127 See Delay Filter Table
39 27 Direct/Delay Mix Percent 0: 0% delay, 100% direct
127: 100% delay, 0% direct
See Normalized MIDI
Pan Input Table
CH 1 pan tbl: Direct
CH 2 pan tbl: Delay
40 28 Modulation Depth 0-127
41 29 Modulation Rate =(value x .1 Hz + .1 Hz)
42 2A Modulation Type 0: random
85: sine
127: triangle
43 2B Mix Rate of Change See Tc Table
