C-7
Rev 2.2, 10/31/94
The parameter map shows the location of various entities within the memory space of the 601.
You can access these by using the program/setup data write command (1Dh).
Table 9. Parameter Map
Offset (dec) Description
0-99 Edit Buffer
100-199 RAM Program 1
12800-12899 RAM Program 128
12900-12999 ROM Program 1
25600-25699 ROM Program 128
25700-25835 Global Parameters
Global Parameter
Offset (dec)
Description Value (dec)
25700 MIDI Channel 0-15
127:OMNI
25701 MIDI Unit 0-126
127: all
25702 Current Pgm range: 0-127
LSB 7 bits program number, 0-255
25703 Current Pgm 0-1 MSB 2 bits of program number
25704 15 dB Microphone Pad
0:OUT, 1: IN
25705 Signal Source 0: AES input 1 to L & R
1: AES input 2 to L & R
2: AES inputs summed to L & R
3: AES inputs to L & R (stereo)
4: Analog input 1 to L & R
5: Analog input 2 to L & R
6: Analog inputs summed to L & R
7:Analog inputs to L & R, independent gain controls (stereo)
25706 Signal/Clock
Configuration
BIT0: 0:DSP->DAC
1:AES->DAC
BIT2: 0:ADC->INPUT
1:AES->INPUT
BIT1: 0:ADC->MCLK
1:AES->MCLK
BIT4: 0:44.1 kHz sample rt
1:48.0 kHz sample rt
25707 MIDI echo 0: no echo
1: echo
25708 Memory protect 0: no protection
1: protected
25709 Reserved
25710 Reserved
25711 Front panel lockout 0:enabled, 85: partial 127:maximum
25712 Reserved
25713 Current sample rate 1:48khz, 2:44.1khz (read only)
25714-5 full left pan see below
25774-5 center
25834-5 full right pan
The pan table (locations 25714-25835) is loaded from the default pan table when the 601 is
first initialized . The table consists of 61 pairs of left-right attenuation values. These values may
be edited should your application require something different. The new values survive power
on/off cycles.
