Symetrix 601 - Table 6. Program;Setup Data Write; Table 7. Identify Request; Table 8. Identify Response

C-6
Rev 2.2, 10/31/94
Table 6. Program/Setup Data Write
DATA TO 601
Type
Long
Purpose
Write a block of parameters by
address
Data ordering
Edit Buffer | 128 User Programs | 128 ROM
Programs | Machine Setup
Off.
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfrID 1> 0
3 <mfrID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F (all)
6 <command> 1D
7 <Offset to start of
data, top 2 bits>
8 <Offset to start of
data, middle 7 bits>
9 <Offset, bottom 7
bits>
10 <number of bytes,
top 2 bits>
11 <number, middle 7
bits>
12 <number, bottom 7
bits>
13 data bytes
... data
... data
<EOX> F7
Table 7. Identify Request
REQUEST TO 601
Purpose
Request the identity of a 601.
Off
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfrID 1> 0
3 <mfrID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F (all)
6 <command> 13
7 <EOX> F7
Table 8. Identify Response
RESPONSE FROM 601
Purpose
601 response to Identify Request
(13h).
Off
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfrID 1> 0
3 <mfrID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F (all)
6 <command> 3
7 <MIDI channel#> 0-0F, 7F
(omni)
8 'S'
9 'Y'
10 'M'
11 'E'
12 'T'
13 'R'
14 'I'
15 'X'
16 ' '
17 '6'
18 '0'
19
'
1'
20 <EOX> F7
