C-13
Rev 2.2, 10/31/94
Table 24. Realtime MIDI Block 2
Offset Description Range Reference
dec hex dec
76 4C Control Type 0: None/Off (default)
1: Control Change
2: Aftertouch
3: Pitch bend (msb 7 bit)
4: Delay section modulation
oscillator 1
5: Delay section modulation
oscillator 2
6: Log signal level, dynamics
section
7: NR center freq
8: Instantaneous gain-
reduction value, compressor
9: Instantaneous gain-
reduction value, expander
10: Block 1 output
77 4D 3 Byte MIDI Message Second
Parameter
0-127
78 4E Control Offset (dec) 0-127
64: 0
0: -128
127:+127
79 4F Control Scaling 0-127
64: No Effect
0: -4
127: +4
Realtime Scaling Table
80 50 Parameter to Modify (Offset
(dec))
Edit Buffer Offset Address
(0-70)
The Program Name (offset 84-99) is not accessible from the front panel; it is only accessible via
MIDI. You can use this with an external MIDI editor to give your 601 programs meaningful (to
you) names.
Table 25. Miscellaneous
Offset Description Range Reference
dec hex dec
81 51 Realtime Block 1 Floor Clip 0-127 Block 1 only. Minimum
normalized edit buffer
value
82 52 Realtime Block 1 Ceiling Clip 0-127
0: 127
127: 0
Block 1 only. Maximum
normalized edit buffer
value.
83 53 Makeup Gain 0-127
0: auto makeup gain
1: 0 dB makeup gain
127: 24 dB makeup gain
Shared between AGC &
Compressor
Attn24 Table
84-99 54-63 Program name ASCII program name
99 63 Modified flag Forced to "*" if program
modified from front
panel
