Symetrix 601 - Table 4. Program;Setup Data Request; Table 5. Data Response

C-5
Rev 2.2, 10/31/94
Table 4. Program/Setup Data
Request
REQUEST TO 601
Type
Long
Requests
Block of parameters by address
See Parameter Map for address Range (hex)
Off
(dec)
Value (hex) Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfrID 1> 0
3 <mfrID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F (all)
6 <command> 12
7 <Offset to start of
data, top 2 bits>
8 <Offset, middle 7
bits>
9 <Offset, bottom 7
bits>
10 <number of bytes,
top 2 bits>
special case:
0,0,0 - transmit
one edit buffer
size worth
11 <number of bytes,
middle 7 bits>
special case: 7F,
7F, 7F -
transmit all
12 <number, bottom
7 bits>
13 <EOX> F7
Table 5. Data Response
RESPONSE FROM 601
Type
Long
Requests
Block of parameters by Offset (dec)
Data ordering
Edit Buffer | 128 User Programs | 128 ROM
Programs | Machine Setup
Off
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfrID 1> 0
3 <mfrID 2> 5E
4 <device type> 0
5 <unit/channel> 0-7E, 7F (all)
6 <command> 1D
7 <Offset to start of
data, top 2 bits>
8 <Offset, middle 7
bits>
9 <Offset, bottom 7
bits>
10 <number of bytes,
top 2 bits>
11 <number, middle 7
bits>
12 <number, bottom 7
bits>
13 <first parameter> 0-7F
- ...
- ...
13+b
ytes
<EOX> F7
