Symetrix 601 - Table 36. Time Constant Table; Table 37. Compresser;Expander Knee Table (in Db)

C-17
Rev 2.2, 10/31/94
Table 35. ARM Threshold (dB)
0123456789
0:
OFF OFF OFF OFF -0.1 -0.1 -0.1 -0.1 -0.2 -0.2
10:
-0.2 -0.2 -0.4 -0.4 -0.4 -0.4 -0.6 -0.6 -0.6 -0.6
20:
-0.8 -0.8 -0.8 -0.8 -1.0 -1.0 -1.0 -1.0 -1.2 -1.2
30:
-1.2 -1.2 -1.5 -1.5 -1.5 -1.5 -1.8 -1.8 -1.8 -1.8
40:
-2.0 -2.0 -2.0 -2.0 -2.2 -2.2 -2.2 -2.2 -2.5 -2.5
50:
-2.5 -2.5 -2.8 -2.8 -2.8 -2.8 -3.0 -3.0 -3.0 -3.0
60:
-3.2 -3.2 -3.2 -3.2 -3.5 -3.5 -3.5 -3.5 -3.8 -3.8
70:
-3.8 -3.8 -4.0 -4.0 -4.0 -4.0 -4.5 -4.5 -4.5 -4.5
80:
-5.0 -5.0 -5.0 -5.0 -5.5 -5.5 -5.5 -5.5 -6.0 -6.0
90:
-6.0 -6.0 -6.5 -6.5 -6.5 -6.5 -7.0 -7.0 -7.0 -7.0
100:
-7.5 -7.5 -7.5 -7.5 -8.0 -8.0 -8.0 -8.0 -8.5 -8.5
110:
-8.5 -8.5 -9.0 -9.0 -9.0 -9.0 -9.5 -9.5 -9.5 -9.5
120:
-10.0 -10.0 -10.0 -10.0 -12.0 -12.0 -12.0 -12.0
Table 36. Time Constant Table
0123456789
0:
100
µ
s 150
µ
s 200
µ
s 250
µ
s 300
µ
s 350
µ
s 400
µ
s 500
µ
s 600
µ
s 700
µ
s
10:
800
µ
s 900
µ
s 1.0ms 1.5ms 2.0ms 2.5ms 3.0ms 3.5ms 4.0ms 4.5ms
20:
5.0ms 5.5ms 6.0ms 7.0ms 8.0ms 9.0ms 10ms 12ms 14ms 16ms
30:
18ms 20ms 22ms 24ms 26ms 28ms 30ms 32ms 34ms 36ms
40:
38ms 40ms 45ms 50ms 55ms 60ms 65ms 70ms 75ms 80ms
50:
85ms 90ms 95ms 100ms 110ms 120ms 130ms 140ms 150ms 160ms
60:
170ms 180ms 190ms 200ms 210ms 220ms 230ms 240ms 250ms 260ms
70:
270ms 280ms 290ms 300ms 320ms 340ms 360ms 380ms 400ms 420ms
80:
440ms 460ms 480ms 500ms 520ms 540ms 560ms 580ms 600ms 620ms
90:
640ms 660ms 680ms 700ms 725ms 750ms 775ms 800ms 850ms 900ms
100:
925ms 950ms 975ms 1.0s 1.1s 1.2s 1.3s 1.4s 1.5s 1.6s
110:
1.7s 1.8s 1.9s 2.0s 2.5s 3.0s 3.5s 4.0s 4.5s 5.0s
120:
5.5s 6.0s 6.5s 7.0s 7.5s 8.0s 9.0s 10.0s
Table 37. Compresser/Expander Knee Table (in db)
0123456789
0:
6666666666
10:
6666666666
20:
6666666666
30:
6 6 1212121212121212
40:
12 12 12 12 12 12 12 12 12 12
50:
12 12 12 12 12 12 12 12 12 12
60:
12 12 12 12 18 18 18 18 18 18
70:
18 18 18 18 18 18 18 18 18 18
80:
18 18 18 18 18 18 18 18 18 18
90:
18 18 18 18 18 18 24 24 24 24
100:
24 24 24 24 24 24 24 24 24 24
110:
24 24 24 24 24 24 24 24 24 24
120:
24 24 24 24 24 24 24 24
