Symetrix 601 - Table 38. Makeup Gain Table (Attn 24; Table 39. Sidechain Lookahead Time (Ms) Table; Table 40. Delay Time Table ( Ms

C-18
Rev 2.2, 10/31/94
Table 38. Makeup Gain Table (Attn24)
0123456789
0:
+0.0 +0.0 +0.0 +0.5 +0.5 +0.5 +1.0 +1.0 +1.5 +1.5
10:
+1.5 +2.0 +2.0 +2.0 +2.5 +2.5 +3.0 +3.0 +3.0 +3.5
20:
+3.5 +4.0 +4.0 +4.0 +4.5 +4.5 +4.5 +5.0 +5.0 +5.5
30:
+5.5 +5.5 +6.0 +6.0 +6.5 +6.5 +6.5 +7.0 +7.0 +7.0
40:
+7.5 +7.5 +8.0 +8.0 +8.0 +8.5 +8.5 +8.5 +9.0 +9.0
50:
+9.5 +9.5 +9.5 +10.0 +10.0 +10.5 +10.5 +10.5 +11.0 +11.0
60:
+11.0 +11.5 +11.5 +12.0 +12.0 +12.0 +12.5 +12.5 +13.0 +13.0
70:
+13.0 +13.5 +13.5 +13.5 +14.0 +14.0 +14.5 +14.5 +14.5 +15.0
80:
+15.0 +15.5 +15.5 +15.5 +16.0 +16.0 +16.0 +16.5 +16.5 +17.0
90:
+17.0 +17.0 +17.5 +17.5 +17.5 +18.0 +18.0 +18.5 +18.5 +18.5
100:
+19.0 +19.0 +19.5 +19.5 +19.5 +20.0 +20.0 +20.0 +20.5 +20.5
110:
+21.0 +21.0 +21.0 +21.5 +21.5 +22.0 +22.0 +22.0 +22.5 +22.5
120:
+22.5 +23.0 +23.0 +23.5 +23.5 +23.5 +24.0 +24.0
Table 39. Sidechain Lookahead Time (ms) Table
0123456789
0:
0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.15 0.17 0.19
10:
0.21 0.23 0.25 0.27 0.29 0.31 0.33 0.35 0.37 0.40
20:
0.42 0.44 0.46 0.48 0.50 0.52 0.54 0.56 0.58 0.60
30:
0.62 0.65 0.67 0.69 0.71 0.73 0.75 0.77 0.79 0.81
40:
0.83 0.85 0.87 0.90 0.92 0.94 0.96 0.98 1.00 1.02
50:
1.04 1.06 1.08 1.10 1.12 1.15 1.17 1.19 1.21 1.23
60:
1.25 1.27 1.29 1.31 1.33 1.35 1.37 1.40 1.42 1.44
70:
1.46 1.48 1.50 1.52 1.54 1.56 1.58 1.60 1.62 1.65
80:
1.67 1.69 1.71 1.73 1.75 1.77 1.79 1.81 1.83 1.85
90:
1.87 1.90 1.92 1.94 1.96 1.98 2.00 2.02 2.04 2.06
100:
2.08 2.10 2.12 2.15 2.17 2.19 2.21 2.23 2.25 2.27
110:
2.29 2.31 2.33 2.35 2.37 2.40 2.42 2.44 2.46 2.48
120:
2.50 2.52 2.54 2.56 2.58 2.60 2.62 2.65
Table 40. Delay Time Table (ms)
0123456789
0:
0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
10:
6789101112131415
20:
16 17 18 19 20 21 22 23 24 25
30:
26 27 28 29 30 32 34 36 38 40
40:
42 44 46 48 50 52 54 56 58 60
50:
62 64 66 68 70 72 74 76 78 80
60:
82 84 86 88 90 92 94 96 98 100
70:
105 110 115 120 125 130 135 140 145 150
80:
155 160 165 170 175 180 185 190 195 200
90:
205 210 215 220 225 230 235 240 245 250
100:
255 260 265 270 275 280 285 290 295 230
110:
235 240 245 250 255 260 265 270 275 280
120:
285 290 295 300 305 310 320 330
