Symetrix 601 - C.1.5 Recognized MIDI Commands

C-4
Rev 2.2, 10/31/94
C.1.5 Recognized MIDI Commands
The 601 recognizes the following MIDI
sysex messages:
Cmd#
(hex)
Command Description
11 Edit buffer data request
1 Edit buffer data response
1C Edit buffer data set
12 Program/Setup data request
1D Data response
1D Program/Setup data write
13 Identity Request
3 Identity Response
Table 1. Edit Buffer Data Request
REQUEST TO 601
Type
Short
Requests
One parameter by number
Off
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfdID 1> 0
3 <mfdID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F(all)
6 <command> 11
7 <parameter offset> 0-7F
8 <EOX> F7
Table 2. Edit Buffer Data Response
DATA FROM 601
Type
Short
Returns
One parameter in Edit Buffer
Off
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfdID 1> 0
3 <mfdID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F (all)
6 <command> 1
7 <parameter #> 0-7F
8 <parameter value> 0-7F
9 <EOX> F7
Table 3. Edit Buffer Data Set
DATA TO 601
Type
Short
Returns
One parameter in Edit Buffer
Off
(dec)
Value Range (hex)
0 <sysex> F0
1 <mfrID 0> 0
2 <mfrID 1> 0
3 <mfrID 2> 5E
4 <device type>
1
5 <unit/channel> 0-7E, 7F (all)
6 <command> 1C
7 <parameter offset > 0-7F
8 <parameter value> 0-7F
9 <EOX> F7
