Symetrix 601 - Table 41. Delay Feedback Table: Negative then Positive Feedback (Db); Table 42. Delay Line Filter Table; Table 43. Realtime Scaling Table

C-19
Rev 2.2, 10/31/94
Table 41. Delay Feedback Table: Negative then Positive feedback (dB)
0123456789
0:
0.0 0.0 -0.1 -0.2 -0.3 -0.4 -0.5 -1.0 -1.5 -1.5
10:
-2.0 -2.5 -3.0 -3.5 -4.0 -4.5 -5.0 -5.5 -5.5 -6.0
20:
-6.5 -7.0 -7.5 -8.0 -8.5 -9.0 -9.0 -9.5 -10.0 -11.0
30:
-12.0 -13.0 -14.0 -15.0 -16.0 -16.0 -17.0 -18.0 -19.0 -20.0
40:
-22.0 -24.0 -26.0 -26.0 -28.0 -30.0 -32.0 -34.0 -36.0 -38.0
50:
-40.0 -42.0 -42.0 -44.0 -46.0 -48.0 -50.0 -55.0 -60.0 -65.0
60:
-65.0 -70.0 -80.0 -90.0 -100 -90.0 -80.0 -70.0 -65.0 -65.0
70:
-60.0 -55.0 -50.0 -48.0 -46.0 -44.0 -42.0 -42.0 -40.0 -38.0
80:
-36.0 -34.0 -32.0 -30.0 -28.0 -26.0 -26.0 -24.0 -22.0 -20.0
90:
-19.0 -18.0 -17.0 -16.0 -16.0 -15.0 -14.0 -13.0 -12.0 -11.0
100:
-10.0 -9.5 -9.0 -9.0 -8.5 -8.0 -7.5 -7.0 -6.5 -6.0
110:
-5.5 -5.5 -5.0 -4.5 -4.0 -3.5 -3.0 -2.5 -2.0 -1.5
120:
-1.5 -1.0 -0.5 -0.4 -0.3 -0.2 -0.1 0.0
Table 42. Delay Line Filter Table (Hz)
0123456789
0: 600 600 600 600 800 800 800 800 1000 1000
10: 1000 1000 1500 1500 1500 1500 2000 2000 2000 2000
20: 2500 2500 2500 2500 3000 3000 3000 3000 3500 3500
30: 3500 3500 4000 4000 4000 4000 4500 4500 4500 4500
40: 5000 5000 5000 5000 5500 5500 5500 5500 6000 6000
50: 6000 6000 6500 6500 6500 6500 7000 7000 7000 7000
60: 7500 7500 7500 7500 8000 8000 8000 8000 8500 8500
70: 8500 8500 9000 9000 9000 9000 9500 9500 9500 9500
80: 10000 10000 10000 10000 10500 10500 10500 10500 11000 11000
90: 11000 11000 11500 11500 11500 11500 12000 12000 12000 12000
100: 13000 13000 13000 13000 13500 13500 13500 13500 14000 14000
110: 14000 14000 15000 15000 15000 15000 16000 16000 16000 16000
120: 17000 17000 17000 17000 18000 18000 18000 18000
Table 43. Realtime Scaling Table
0123456789
0:
-4.0 -3.8 -3.6 -3.4 -3.2 -3.0 -2.8 -2.6 -2.4 -2.2
10:
-2.0 -1.9 -1.8 -1.7 -1.6 -1.5 -1.4 -1.3 -1.2 -1.1
20:
-1.0 -0.95 -0.90 -0.85 -0.80 -0.75 -0.70 -0.65 -0.60 -0.58
30:
-0.56 -0.54 -0.52 -0.50 -0.48 -0.46 -0.44 -0.42 -0.40 -0.38
40:
-0.36 -0.34 -0.32 -0.30 -0.28 -0.26 -0.24 -0.22 -0.20 -0.18
50:
-0.16 -0.14 -0.12 -0.10 -0.09 -0.08 -0.07 -0.06 -0.05 -0.04
60:
-0.03 -0.02 -0.01 0.0 0.0 0.01 0.02 0.03 0.04 0.05
70:
0.06 0.07 0.08 0.09 0.10 0.12 0.14 0.16 0.18 0.20
80:
0.22 0.24 0.26 0.28 0.30 0.32 0.34 0.36 0.38 0.40
90:
0.42 0.44 0.46 0.48 0.50 0.52 0.54 0.56 0.58 0.60
100:
0.65 0.70 0.75 0.80 0.85 0.90 0.95 1.0 1.1 1.2
110:
1.3 1.4 1.5 1.6 1.7 1.8 1.9 2.0 2.2 2.4
120:
2.6 2.8 3.0 3.2 3.4 3.6 3.8 4.0
