Symetrix 601 - 4.10 Setting Scenarios

4-17
Rev 2.2, 10/31/94
LEAVE EDIT Switch The LEAVE EDIT switch terminates any editing
operation without disturbing or destroying the
contents of the edit buffer. You use this switch to
return to the top-most control mode (program
number shows in display).
4.10 Setting Scenarios
The following scenarios may help clarify setting up the 601 for various analog and/or digital
input signals.
Situation 1: Internal ADC (mic or line), internal sample clock, DACs fed from DSP.
r Under globals, click to
InP . Set left-hand input LEDs to MIC or LINE.
r Click globals again to
C--- or CLCI or CLCE . Set to CLCI for internal master sample clock.
r Click globals again to
44.1 or 48.0. Select sample rate.
Situation 2: Internal ADC (mic or line), external sample clock, DACs fed from DSP.
r Under globals, click to
InP . Set left-hand input LEDs to MIC or LINE.
r Click globals again to
C--- or CLCI or CLCE . Set to CLCE for master sample clock from
AES/EBU reference.
r Connect external sample clock source to AES/EBU input.
Situation 3: Input from AES/EBU, external sample clock, DACs from DSP.
r Under globals, click to
InP . Set left input LEDs to digital.
r Click globals again to
C--- or CLCI or CLCE . Clock and signal source will be forced to
external AES/EBU.
